PRN Serie

"The economical"

Concentration on the essentials

The most economic type of swivelling reduces your production costs

Dampened end position

Using the hydraulic brake allows you to move up to the end positions gently, increasing the process reliability and durability of your application

Forged drive shaft

This shaft is not only robust, but can be individually adjusted, e.g. with supply holes through the axis

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN1-90-B	PDF	0.15 [Nm]	90 [°]	0.1 [s]
PRN1-180-B	PDF	0.15 [Nm]	180 [°]	0.17 [s]
PRN1-270-B	PDF	0.15 [Nm]	270 [°]	0.24 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN3-90-B	PDF	0.38 [Nm]	90 [°]	0.13 [s]
PRN3-180-B	PDF	0.38 [Nm]	-	0.2 [s]
PRN3-270-B	PDF	0.38 [Nm]	270 [°]	0.28 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN10-90-B	PDF	1.2 [Nm]	90 [°]	0.13 [s]
PRN10-180-B	PDF	1.2 [Nm]	180 [°]	0.2 [s]
PRN10-270-B	PDF	1.2 [Nm]	270 [°]	0.28 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN20-90-B	PDF	2.1 [Nm]	90 [°]	0.14 [s]
PRN20-180-B	PDF	2.1 [Nm]	180 [°]	0.25 [s]
PRN20-270-B	PDF	2.1 [Nm]	270 [°]	0.34 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN30-90	PDF	4.1 [Nm]	90 [°]	0.17 [s]
PRN30-180	PDF	4.1 [Nm]	180 [°]	0.33 [s]
PRN30-270	PDF	4.1 [Nm]	270 [°]	0.5 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN50-90	PDF	12.8 [Nm]	90 [°]	0.17 [s]
PRN50-180-B	PDF	5.9 [Nm]	180 [°]	0.33 [s]
PRN50-270	PDF	5.9 [Nm]	270 [°]	0.5 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN150-90	PDF	41.5 [Nm]	90 [°]	0.25 [s]
PRN150-180-B	PDF	18 [Nm]	180 [°]	0.38 [s]
PRN150-270	PDF	18 [Nm]	270 [°]	0.63 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN300-90	PDF	83 [Nm]	90 [°]	0.33 [s]
PRN300-180-B	PDF	34.5 [Nm]	180 [°]	0.5 [s]
PRN300-270	PDF	34.5 [Nm]	270 [°]	0.71 [s]

Artikelcode	Download	Torque	Swivel angle	Swivel time
PRN800-90	PDF	247 [Nm]	90 [°]	0.45 [s]
PRN800-270	PDF	123 [Nm]	270 [°]	1 [s]
PRN800-100	PDF	247 [Nm]	100 [°]	0.45 [s]
